MODEL | DELL R940 Poweredge Rack Server |
Processor | 4x 2nd Generation Intel Xeon Processor Scalable Family Gold and Platinum |
Memory | 48x DDR4 RDIMM/LRDIMM • 12x NVDIMM DCPMM 12.28 TB (15.36 TB with LRDIMM) |
Storage controllers | S140, HBA330, H330, H730, H730P, H740P, H840 (external), and 12 Gbps SAS HBA (external) |
Drive Bays | 4 x 2.5-inch NVMe only • 8 x 2.5-inch SAS/SATA or SATA only 24 x 2.5-inch SAS/SATA 32 x 2.5-inch SAS/SATA or SATA only |
Power Supplies | AC (Platinum): • 1100 W • 1600 W • 2000 W • 2400 W AC (Titanium): • 750 W DC: • 1100 W Mix Mode: 750 W (for China only) Mix Mode/HVDC (China and Japan only): • 1100 W |
Embedded management | iDRAC9 |
Form Factor | 3U rack server |
I/O & Ports | 4 x 1GbE +2 x 10GbE + 2 x 1GbE+4 x 10GbE +2 x 25GbE |
Warranty | 3 years |
